FrostyTech Latest Cooling News

Visit DeepCool at CeBIT - Hall 17, A11-15

BY: Frostytech.com — Fri, 24 Feb 2012 14:13:20

Scythe introducing Katana 4 at CeBIT 2012 fair

BY: Frostytech.com — Wed, 22 Feb 2012 15:52:11

Japanese cooling expert Scythe is going to show brand new products at the famous CeBIT trade show in Hannover (Germany) from 6th until 10th March 2012. Scythe booth will be located in the planet reseller hall 15 at the booth number F44, which is organized in a cooperation with its partner Wave Computersysteme GmbH. Interested visitors will be able to discover brand new Scythe products.

Soon to be release Katana 4 CPU Cooler is providing a first outlook into future Scythe product designs. Katana 4 is Scythes this year's exhibition highlight, introducing the innovative fin structure design called A.T.F.S. (Aero Tuning Fin Structure). A.T.F.S. tilted structure utilizes the intake holes for additional precise airflow, maximizing the Katana 4 CPU Cooler's efficiency. In addition, Katana 4 is equipped with the brand new mounting clip set by the name N.G.C.S. (New Generation Clip System). Hence allows the 480 grams cooler to be mounted on latest sockets, providing maximum socket compatibility.

Furthermore, visitors will be able to experience Scythe's top seller products as well as two new digital amplifiers from Scythe audio product portfolio. In particular Scythe will exhibit the two newcomer amplifiers Kama Bay Amp Pro (SDAR-3000) and Kama Bay Amp Mini Pro (SDA35-2000). Both amps are class D amplifiers, which differ in size, design as well as specs. Double decker Kama Bay Amp Pro (SDAR-3000) is utilizing a powerful Toshiba� TB2924AFG IC, providing 16 watts of continuous output per channel and a multitude of features.

Compact Kama Bay Amp Mini Pro fits into a common 8,89 cm respectively 3,5 inch bay of a pc chassis. Built-in MAX98400A Power IC from MAXIM� allows continuous output of 24 watts per channel. Despite the compact size, Kama Bay Amp Mini Pro is equipped with many features and offers even a Line-in and USB Power connector in the front. [SCYTHE-USA] via [Frostytech.com]

MSI Reveals HD 7700 Series Dual-Fan Graphic

BY: Frostytech.com — Wed, 22 Feb 2012 09:03:00

Today the internationally renowned graphics card and mainboard maker MSI released two new graphics cards. The R7770-2PMD1GD5/OC and R7750-PMD1GD5/OC feature the new Radeon HD 7700 GPU based on AMD's latest 28nm process with support for PCI Express Gen3. Core voltage adjustment is supported by the MSI R7700 graphics card. The R7770-2PMD1GD5/OC GPU core frequency can be overclocked by up to 32.4% using MSI's exclusive Afterburner graphics card overclocking utility to reach an amazing 1.35GHz*! MSI's R7700 series graphics cards also feature a customized dual-fan thermal design that effectively reduces the GPU operating temperature and ensures stable performance. Integrated support for 3D video, high-quality DisplayPort 1.2 and HDMI 1.4a outputs, along with AMD's exclusive Eyefinity multiple display output technologies make these the perfect choice for enthusiasts. [MSI.COM] via [Frostytech.com]

TMEIII universal cpu cooler from Spire

BY: Frostytech.com — Tue, 21 Feb 2012 16:20:09

The TMEIII is the next evolution of the hugely successful TherMax Eclipse CPU cooler series. The increased number of heat-pipes combined with a higher number and density of dimpled fins. Crowned with two (2pcs) high airflow, Nano-Bearing DC fans for extreme cooling performance. Five (5) U-shaped 8mm all-copper heat-pipes are in direct contact with the CPU heat-spreader (heat source), rapid heat transfer to the 45 aluminum dimpled fins providing a larger surface area for optimum heat dissipation. The TME III is supplied with two (2) 12cm BlackStar 7 blades, high quality precision Nano-Bearing DC fans, providing high airflow and sufficient cooling. These fans are PWM controlled to provide the best sound / cooling ratio possible. Compatibility is guaranteed with multi-platform mounting for all current Intel and AMD micro-processors. The TME III brings cooling power to an all-new level.

* Five (5) 8mm all copper U-shaped sinter-powder heat-pipes
* Heat-pipe base direct contact with all of the processor area
* Straight lined heat-pipes allowing air to easily pass through
* Stamped aluminum wide fins for best surface area
* Dimpled surface fin for increased heat transfer rate
* All black-Nickel coated heat-pipes to preserve looks from oxidation
* Two (2pcs) 120mm BlackStar 7 blade DC fan included
* High Quality, Long MTBF precision Nano-Bearing fans
* Supports AM2/AM3 socket 939/940/ 775/1155/1156 & 1366/2011
* Best cooling performance on hot CPU's up to TDP 150W
* PWM fan speed control, 4 Pin Mainboard Connector
The TME III Cooler is compatible with the latest ATX and Micro ATX boards based on the Intel Micro-processors sockets 775/1155/1156/1366/2011 and for AMD Micro-processors AM2/AM3/940/939 for AMD (not G34 compatible).
MSRP: USD $64.95 / EUR $48.99 [SPIRE-CORP] via [Frostytech.com]

Glacialtech Igloo 5620 PWM Heatsink Reviewed on Frostytech

BY: Frostytech.com — Tue, 21 Feb 2012 14:31:35

"While the Glacialtech Igloo 5620 PWM heatsink ships with one 92mm fan capable of operating at 2300-800RPM, additional fan clips are supplied for a second user-supplied 92mm fan to be installed if desired. The base of the heatsink makes use of exposed heatpipes to leverage the rapid heat conduction qualities of these thermal devices. Given the relatively compact height of the Igloo 5620 PWM heatsink, it should fit into a good variety of PC cases which are off limits to the vast number of +160mm tall heatsinks." [FROSTYTECH] via [Frostytech.com]

Coolermaster Hyper 612 PWM Heatsink Reviewed on Frostytech

BY: Frostytech.com — Tue, 21 Feb 2012 14:27:39

"On the test bench today is a boxy tower-style processor heatsink from Cooler Master called the Hyper 612 PWM. This is a pseudo-quiet cooling heatsink built around six, 6mm diameter copper heatpipes and a single 120x120mm PWM fan. The fan rotates at 2000-600RPM and offers at best, excellent thermal performance. At the slowest fan speeds you can expect very quiet but generally average performance from the Hyper 612 PWM heatsink."

[FROSTYTECH] via [Frostytech.com]

Noctua NH-L12 low-profile cooler for Small Form Factor cases

BY: Frostytech.com — Tue, 21 Feb 2012 13:46:11

Noctua today presented its new NH-L12 low-profile cooler for Small Form Factor cases and HTPC environments. The NH-L12 features a flexible NF-F12 (120mm) / NF-B9 (92mm) dual PWM fan setup that can be configured either for full performance in dual fan mode or extra-low profile (66mm) with the top fan removed.

"The industry trend towards Small Form Factor and Home Theatre PCs is well-established, but there's still a lack of suitable high-quality quiet CPU coolers", explains Mag. Roland Mossig, Noctua CEO. "Building a powerful PC always requires a capable CPU, which in return demands a competent cooling solution. But who wants his HTPC to sound like a jet engine? This is precisely where the NH-L12 steps in."

Thanks to its exquisite dual fan setup consisting of Noctua's highly optimised NF-F12 (120mm) and NF-B9 (92mm) premium fans, the NH-L12 pushes the bar in terms of low-profile quiet cooling performance. Alternatively, the NH-L12 can also be used with the NF-B9 92mm fan only in order to reduce the overall height to 66mm. This way, the cooler is suitable for many typical �ATX or Mini-ITX enclosures and ideal for whisper-quiet HTPC systems.

The NH-L12's NF-F12 and NF-B9 fans support PWM for convenient automatic speed control. In addition, the maximum fan speed can be reduced to 1200/1300rpm using the supplied Low-Noise Adaptors for even quieter operation. Bundled with the award-winning NT-H1 thermal compound and Noctua's SecuFirm2� multi-socket mounting system, the NH-L12 packs everything a premium quality quiet cooler needs into a highly compact package.

The NH-L12 will be available immediately at a recommended retail price of EUR 49.90 / USD 59.90 [NOCTUA] via [Frostytech.com]

Super-Coolers on LGA 2011 Platform

BY: Frostytech.com — Tue, 21 Feb 2012 09:03:00

Today we are going to compare the cooling efficiency of the best air-coolers out there and one mainstream liquid cooling solution in a system with Intel Core i7-3960X Extreme Edition inside. [XBITLABS] via [Frostytech.com]

Nofan CR-95C IcePipe 95W Fanless CPU Cooler Review

BY: Frostytech.com — Tue, 21 Feb 2012 03:31:57

"Pretty apt name when you think about it "Nofan" produce passive and 100% silent CPU coolers, you are probably already think if its passive it has to be really hot though right? Well that's what we thought to be honest, but you really need to read on because this review might surprise you a bit!Things to point out really are that with it being fanless that means that its 100% silent and wont get clogged up with dust over time and for this reason the temperatures should not creep up due to there being no dust starting to insulate the heat sink. So although we had to alter our testing to fit within the supported hardware of the CR-95 it has performed well enough to shock us...." [OVERCLOCK3D] via [Frostytech.com]

Thermaltake Bigwater A80 Liquid-Cooling System Review

BY: Frostytech.com — Mon, 20 Feb 2012 09:02:00

This is the story of yet another company that decided to follow the footsteps of Antec, Corsair and CoolIt and give it a try with a new compact cooling system. [XBITLABS] via [Frostytech.com]

Scythe Susanoo mATX motherboard Heatsink

BY: Frostytech.com — Sun, 19 Feb 2012 14:27:41

Interesing review on Akiba of this large heatsink, it's the size of a mATX motherboard. Check it out here.

[SCYTHE] via [Frostytech.com]

Coolermaster Gemini II SF524 Cooler Review

BY: Frostytech.com — Sun, 19 Feb 2012 09:01:00

The new Gemini II range is shooting across the net as Coolermaster release a new wave of coolers. One of the latest on the UK market is the Gemini II SF524 CPU Cooler, of which we have for you today. The Gemini II SF524 is a low profile product with a great aesthetic design... [HARDWARELOOK] via [Frostytech.com]

Tich� PC HDD Vibration Killer

BY: Frostytech.com — Sat, 18 Feb 2012 09:00:00

The Tich� PC HDD Vibration Killer is an aftermarket internal hard drive suspension system that is simple but effective and cost efficient. http://www.silentpcreview.com/tichepc-hdd-vib-killer [SILENTPCREVIEW] via [Frostytech.com]

Shagon' ARC-118

BY: Frostytech.com — Fri, 17 Feb 2012 09:02:00

Vor kurzem pr�sentierten wir schon ein Review zum Neueinsteiger Shagon'. Der AHC-118 baute auf einen 120-mm-L�fter und sechs Heatpipes. Des Weiteren war er von den Abma�en kein Winzling und kann bei einigen Geh�usen zu Problemen f�hren. Shagon' hat deswegen zeitgleich einen kleineren K�hler ver�ffentlicht, den ARC-118. Dieser baut auf einen 92-mm-L�fter und nur vier Heatpipes, die ebenfalls wie beim gro�en Bruder mittels H.D.T. die Abw�rme direkt vom Prozessor aufnehmen. Was man vom kleineren der beiden K�hler erwarten kann und ob er besser abschneidet als der AHC-118, kl�ren wir im folgenden Review. [DEXGO] via [Frostytech.com]

500GB Seagate FreeAgent GoFlex Ultra-Portable Hard Drive Review

BY: Frostytech.com — Thu, 16 Feb 2012 18:40:43

"The Seagate FreeAgent GoFlext Ultra-Portable hard drive is more than just a portable 2.5" SATA HDD. key to the system's brilliant usefulness is that Seagate designed this hard drive to interface with a series of modular cable interface adaptors, docks and a media player. It's what you'd call, really very flexible." [PCSTATS] via [Frostytech.com]

Noctua's DH-14: Air Cooling Keeps Up With Liquid?

BY: Frostytech.com — Thu, 16 Feb 2012 09:03:00

A few months back, we examined the performance of four liquid coolers for the Sandy Bridge-E socket LGA 2011 platform: Corsair's H80 and H100, Maingear's Epic 180, and Intel's own reference cooler. Liquid coolers are popular with high-end OEMs and some enthusiasts, but they aren't cheap -- and there's a certain group of enthusiasts who aren't comfortable with flowing liquid in their systems. Recently, we spoke with the team at Noctua, who offered to send us one of its high-end air coolers for comparison. We've been curious about the company since it came across our radar with its upgrade offer for anyone upgrading to Socket 2011 last year. The Noctua DH-14 is a mammoth air cooler that competes performance-wise with many self-contained liquid coolers. Check it out... [HOTHARDWARE] via [Frostytech.com]

ARCTIC Accelero TwinTurbo II VGA cooler

BY: Frostytech.com — Thu, 16 Feb 2012 09:01:00

Hardwareoverclock.com has just posted another review. Last week we take a look at the ARCTIC Accelero TwinTurbo II VGA cooler. The testing card was a GTX 560 TI 448. The results are amazing [HARDWAREOVERCLOCK] via [Frostytech.com]

The Laws of Physics at Play - Sleeve Bearing Fundamentals

BY: Frostytech.com — Thu, 16 Feb 2012 02:02:06

In case you missed it, these videos were posted on Frostytech's Facebook page a couple days ago. Fantastically informative 1960's era university level films that visualize various Fluid Mechanics topics. Focusing on Low Reynolds Number Flow, what's interesting about these two videos is bit about pressure distribution about a journal bearing - essentially a sleeve bearing used in most computer fans.

Watch from 7:44.

Continue, for the first half of this video.

Frostytech covered sleeve bearings 12 years ago, you can see the same forces graphed here. [FROSTYTECH] via [Frostytech.com]

The Laws of Physics at Play - Turblent + Laminar Flow

BY: Frostytech.com — Wed, 15 Feb 2012 15:09:31

In case you missed it, these videos were posted on Frostytech's Facebook page a couple days ago. Fantastically informative 1960's era university level films on visualizing Fluid Mechanics properties such as constrained flow, boundary layers, turbulent & laminar flow, pressure, etc. We hope you find them interesting, they illuminate many of the fundamental laws of physics which come into play with forced air cooled heatsinks.

[FACEBOOK] via [Frostytech.com]

The Laws of Physics at Play - Boundary Layers

BY: Frostytech.com — Wed, 15 Feb 2012 15:09:20

[FACEBOOK] via [Frostytech.com]

The Laws of Physics at Play - Flow Visualization

BY: Frostytech.com — Wed, 15 Feb 2012 15:09:10

[FACEBOOK] via [Frostytech.com]

The Laws of Physics at Play (video 1)

BY: Frostytech.com — Wed, 15 Feb 2012 15:09:00

[FB] via [Frostytech.com]

DeepCool goes gunning for Noctua. Really?

BY: Frostytech.com — Wed, 15 Feb 2012 14:59:23

Almost never spotted in the wild, Noctua engineers have been responsible for some of the finest sandwiches [sorry, coolers - Ed] in human history. If you catch a glimpse of Zardon in the lab, with his 2600k nuts clocked past 5GHz and the breeze from the cooling solution blowing his hair back, then you can be sure it will be a Noctua. But a small outfit from Beijing wants to change all that. Enter the DeepCool. [KITGURU.US2.LIST-MANAGE1.COM] via [Frostytech.com]

Notepal X3 Review

BY: Frostytech.com — Wed, 15 Feb 2012 09:03:00

A beefy new laptop cooler from Cooler Master featuring a 200mm fan." [FUSIONMODS] via [Frostytech.com]

GlacialLight Exhibiting at LED China 2012

BY: Frostytech.com — Mon, 13 Feb 2012 15:08:00

Date: February 20-23, 2012
Venue: Pazhou Complex, Guandzhou, China
Booth #: N410 in Hall 9.3

GlacialLight, a sub-division of the experienced technology manufacturer GlacialTech Inc., is pleased to announce its attendance at the world's largest LED event - LED China 2012 from February 20 to 23, 2012. GlacialLight invites all interested parties to visit their booth (#N410 in Hall 9.3) to test products, ask questions, and procure GlacialLight's most advanced LED lighting solutions offerings.

�LED CHINA has evolved into one of the most influential trade events for the industry. This is the only fair in China where every spectrum of the LED industry is showcased. With exhibits ranging from signage to lighting, display to applications, chips to packaging and equipment to components, the fair offers the most comprehensive one-stop LED sourcing platform. It is expected to comprise near 1,100 exhibitors in 5 specialized sections occupying 70,000 square meters in exhibition space. As an important part of the fair, the LED Lighting sector is projected to draw over 600 lighting companies presenting the latest LED indoor & outdoor lighting products and trends on LED Streetlight, Solar LED Lights, LED Daylight Lamps, LED Decorative Lighting, etc.�

GlacialLight's booth will be featuring several of their newest products including the recently

released GL-FL12, GL-FL30, and GL-FL120 flood lights using Philips Lumileds LED Chips, Pollux Series Panel Lights, Capella Series dimmable down lights, and their innovative LED Drivers that make electronic transformers unnecessary while improving power conversion efficiency as well as reliability.

GlacialLight will also display a wide array of environmentally-friendly and energy-saving products, LEDs with dimming functionality, bay lights, lamp lights, LED tubes, light bar display lights, and streetlight and spotlight solutions.

GlacialLight is looking forward to meeting with current and future business partners, industry leaders and global buyers from all over the world at LED China 2012, Pazhou Complex, Booth # N410, Hall 9.3, during LED EXPO, from February 20th to the 23rd. [GLACIALLIGHT] via [Frostytech.com]

Noctua NF-B9, NF-P12, NF-R8 Fans:

BY: Frostytech.com — Thu, 09 Feb 2012 15:29:38

Late last year we took a look at an interesting 120mm PWM fan from Noctua. Now we have the chance to review the rest of their PWM fans; so let's take a look how well they perform. [RBMODS] via [Frostytech.com]

Spire Kepler Pro CPU Cooler Review

BY: Frostytech.com — Thu, 09 Feb 2012 15:28:39

"Unlike many other CPU coolers that we have reviewed lately, the Spire Kepler Pro actually mounts with a traditional retaining clip rather than screws. I can't state how nice it is to not have to replace all the mounting hardware. Let's see how this $38.95 MSRP cooler performs on our AMD PhenomII X6 1100T Black Edition 3.3Ghz." [TOPREVIEWSHOP] via [Frostytech.com]

Swiftech H20-220 Edge HD Liquid Cooling Kit Review

BY: Frostytech.com — Thu, 09 Feb 2012 15:28:04

"The H2O-220 Edge HD kit from Swiftech is solidly built, easy to install, and performs very well. The configurability of the H2O-220 Edge HD kit is nice as it allows the end user the flexibility to make the cooler fit their need, rather than the other way round..." [LEGITREVIEWS] via [Frostytech.com]

How to Optimize Chassis, Venting and Airflow Design in a Server

BY: Frostytech.com — Wed, 08 Feb 2012 14:42:07

Ever wondered how manufacturers determine airflow within a chassis and design fan placement and heatsink parameters with CFD software? Follow this interesting webinar: here. Of special note is the bit relating to fin height and base thickness towards the end of the webinar... [MENTORGRAPHICS] via [Frostytech.com]

Porsche Showroom Complements its High-End Automobiles with GlacialLight LED Ligh

BY: Frostytech.com — Wed, 08 Feb 2012 14:24:54

GlacialLight's environmentally-friendly LED lighting products recently made their way into a Porsche showroom in Florida, USA. The Porsche showroom replaced their outdated recessed halogen bulbs with GlacialLight's GL-BR30 LED lights. Customers and staff have noticed improved visibility with the LEDs shining bright, natural-looking light with no perceptible flickering.

Not only do GlacialLight LED lights produce higher quality light than halogen bulbs, but they also are much more efficient. The GL-BR30 LED lights consume only 11W respectively. With reduced power consumption the Porsche showroom has realized 83% savings in lighting related energy cost. These LEDs will continue to illuminate the showroom using very little electricity for a long time thanks to their long life spans of over 35,000 hours.

GlacialLight is excited to see its product lines being used to make businesses more successful and at the same time benefiting society by offering lighting products that have longer lifetimes and save more energy than traditional lighting, emit no harmful UV or IR radiation, and contain no hazardous materials such as mercury.

Read more about the GlacialLight GL-BR30 Series at: http://www.glaciallight.com/products/BR30.htm

For more information on how consumers are using GlacialLight�s products visit http://www.glaciallight.com/news/project.htm

The design of LED lighting products is based on three core technologies: electrical design (LED drivers), mechanical design (cooling devices), and optical design (lamp holders).

Benefits of LED lighting compared to traditional lighting

� Directional lighting: ideal for flashlights/torches and spotlights

� No warm-up time in cold environments: LEDs need no warm-up time, unlike conventional CFLs

� No harmful radiation or hazardous metals: LEDs don�t emit harmful radiation, unlike ultraviolet or infrared emitting halogen lamps; and they don�t contain hazardous metals like mercury, which is found in mercury lamps

� Extremely long lifetimes free users from frequent bulb replacement costs

� Extremely small carbon footprint: an environmentally-friendly technology

[GLACIALLIGHT] via [Frostytech.com]

Cooler Master GeminII M4 CPU Cooler Review

BY: Frostytech.com — Wed, 08 Feb 2012 09:00:00

Usually when a CPU cooler is reviewed here at the Shrimps we are talking about high end big and bulky models. Dual towers, triple fan equipped, the bigger the better. But what about for them that are building a high performance HTPC or eg a mini cube ? Do they have to rely solely on the included boxed coolers ? I had the privilege to build a Mine LAN PC inside a Lian Li V353 Cube shaped case. Most important factor was the build's size, not at the cost of performance. The choice of components was pretty high end : Asus Maximus IV Gene, Intel 2600K, 16Gb of Corsair ram, 120 Corsair GT SSD and a Nvidia GTX560 GPU. More than suitable for casual gaming purposes. After the build was completed, we noticed, during stability testing, that the CPU got pretty hot. And it was still running at out of the box speeds. Time to look for a beefier cooling solution Our eye fell onto Cooler Masters' latest low profile CPU cooler : The GeminII M4 CPU cooler. [MADSHRIMPS] via [Frostytech.com]

Danger Den DD-M6 Waterblock Review

BY: Frostytech.com — Sun, 05 Feb 2012 16:03:00

One of the biggest names in watercooling is Danger Den and not because they offer a ton of different products but rather their years of service to the watercooling enthusiast and providing them what they need at just the right time. [NINJALANE] via [Frostytech.com]

Scythe announcing new Kaze Master Pro Ace fan controller

BY: Frostytech.com — Sat, 04 Feb 2012 09:02:00

Japanese cooling expert Scythe is expanding its product portfolio by the new Kaze Master Pro Ace fan controller. The built-in technology is based on the already announced Kaze Master Pro 5.25 fan controller, which now comes with classy aluminum front panel design. Hence allows it to match more pc chassis on the market, especially pc chassis with an aluminum front panel. New Kaze Master Pro Ace fan controller allows users to adjust fan speed of up to fans separately as well as monitoring up to 6 temperature sensors. Adjustments of fan speeds are being made using the 6 potentiometers located in the lower part of the aluminum front panel. Using the other two potentiometers located on the sides, it is possible to choose 2 of the 6 channels to be displayed on the built-in VF-Display (Vacuum Fluorescent Display). [KAZE-MASTER] via [Frostytech.com]

Noctua NH-D14 CPU cooler

BY: Frostytech.com — Fri, 03 Feb 2012 14:52:54

It's clear from the moment you receive the vast box that Noctua means business with its NH-D14 cooler. The heat sink is comfortably the largest we have tested and the cooler comes with two fans as standard. The question is, does it perform as well as it looks?". [ITSHOOTOUT] via [Frostytech.com]

Noctua NF-F12 Focused Flow Fan Review

BY: Frostytech.com — Fri, 03 Feb 2012 14:52:36

In this review we will be looking at the new Noctua NF-F12 PWM Fan which features the new Focused Flow technology for better air penetration and overall pressure. The fan features nine major innovations some of which we have seen on competing products with different levels of refinement. [NINJALANE] via [Frostytech.com]

Noctua NF-F12 120mm PWM Fan Review @ DragonSteelMods

BY: Frostytech.com — Wed, 01 Feb 2012 09:01:00

"When it comes to reviewing products fans just aren�t something very exciting, unless they�re from our friends at Noctua who always seem to be innovating and improving the designs of their fans. They spend quite a bit of time, effort and money on improving fans. Most people take them for granted really. Today for review I�ve got their newest fan called the NF-F12 PWM which is a 120mm fan with lots of new features and it has a very unique look to it. So read on� " [DRAGONSTEELMODS] via [Frostytech.com]

Thermal Interface with a Patterned Structure

BY: Frostytech.com — Wed, 01 Feb 2012 01:50:08

Curiously, I had a discussion with a thermal solutions manufacturer during Computex Taipei, circa-2003/04, about nearly the very same concept that Patent 7282799 - 'Thermal interface with a patterned structure' details. That is, to create very thin, shallow grooves in the base of heatsink to enable the maximal amount of excess thermal interface material to escape from between the heatsink-to-integrated heatspreader contact area.

Physics of course gets the original patent on this, as thermal interface material will naturally do the same thing, given time, heat and clamping force. You can see examples of this after removing a heatsink, provided the base of the heatsink is flat and the clamping forces even. If these conditions exist, you'll see a pattern in the shape of a X going from corner to corner in the remaining thermal goo, with fine fractal patterns sub-dividing the remaining area ad infinitum.

Patent 7282799: Worth the read.

[US PATENT OFFICE] via [Frostytech.com]

A Comparison of Fin Geometries for Heatsinks

BY: Frostytech.com — Wed, 01 Feb 2012 00:42:43

"In this study, the heat transfer performance of various commonly used fin geometries is compared. Realistic, manufacturable geometries are considered for minimizing thermal resistance at moderate laminar air velocities and pressure gradients. These consist of plate fins or pin fins, which can be round, elliptical, or square. The plate fins can be continuous (parallel plates) or staggered. The pin fins can be inline or staggered arrays." [IMAPS.ORG] via [Frostytech.com]

Experimental and theoretical studies of flat plate heat pipes...

BY: Frostytech.com — Tue, 31 Jan 2012 23:37:35

"Since a few years, we have developed experimental benches to visualize the flow in the capillary structure of FPHPs closed with transparent plates. Different capillary structures have been studied (grooves with constant or variable widths, crossed grooves, figure 1) for FPHPs made of copper or silicon. Depending on the applications, we have tested FPHPs with different sizes and different evaporator, condenser and adiabatic areas." [CSC.UTT.FR] via [Frostytech.com]

Now you can follow Frostytech on Facebook!

BY: Frostytech.com — Tue, 31 Jan 2012 14:30:47

Just go here -

- and click on the 'Like' button to follow Frostytech on Facebook. [FACEBOOK] via [Frostytech.com]
